Technical specifications
| Face Capacity | 2,000 |
|---|---|
| Fingerprint Capacity | 3,000 |
| Card Capacity | 3,000 |
| Record Capacity | 100,000 |
| Display | 2.8-inch TFT Screen |
| Communication | RS232/485, TCP/IP, USB -Host |
| Standard Functions | Work Code, SMS, DST, Scheduled-bell, Self-Service Query, Automatic Status Switch ,Photo ID, T9 Input, Camera, 9 digit user ID, Built-in Battery, Multiple Verify Mode, External Bell. |
| Access Control Interface | Lock, Door Sensor, Exit Button, Alarm |
| Wiegand Signal | Output |
| Optional Functions | ID/MF, WDMS |
| Power Supply | DC 12V 3A |
| Operating Temperature | 0 °C- 45 °C |
| Operating Humidity | 20%-80% |
| Dimensions | 173.0×159.0×36.1mm (Length×Width×Thickness) |
