Technical specifications
| Function | Projection (Mobile) |
|---|---|
| Resolution | XGA – 1024 × 768 (4:3) – HD Ready |
| Contrast Ratio | 15,000 : 1 |
| Connectivity | USB 2.0 Type-A, USB 2.0 Type-B, RS-232C, VGA In (2×) |
| Speaker | 5 Watt |
| Weight | 3.1 kg |
| In the Box | Main Unit, Power Cable, Computer Cable |
| Projection System | 3LCD Technology, RGB Liquid Crystal Shutter |
| LCD Panel | 0.55" C2 Fine |
| Color Light Output | 3,400 Lumens (2,200 Lumens Eco) |
| White Light Output | 3,400 Lumens (2,200 Lumens Eco) |
| Aspect Ratio | 4:3 |
| On-Screen Pixel Count | 786,432 |
| Light Source | 210W UHE Lamp |
| Lamp Life | 6,000 Hours (Normal), 12,000 Hours (Eco) |
| Keystone Correction | Manual Vertical ±30°, Manual Horizontal ±30° |
| Color Processing | 10-bit |
| Refresh Rate | 100–120Hz |
| Color Reproduction | Up to 1.07 Billion Colors |
| Throw Ratio | 1.44 – 1.95:1 |
| Zoom | Digital 1.0 – 1.35x |
| Screen Size | 30" – 350" |
| Projection Distance (60") | 1.76 m |
| Lens F Number | F1.44 |
| Focal Length | 16.7 mm |
| Focus | Manual |
| Offset | 8:1 |
| HDMI | 1 × HDMI |
| VGA Input | 2 × VGA |
| VGA Output | 1 × VGA |
| Composite Input | 1 × Composite Video |
| Audio Input | 2 × 3.5mm Jack |
| Audio Output | 1 × Cinch Audio Out |
| USB | USB 2.0 (Display Function: Image / Sound) |
| RS-232C | Yes |
| Epson iProjection | Ad-Hoc / Infrastructure |
| Security | Kensington Lock, Control Panel Lock, Password Protection, Security Cable Hole |
| Color Modes | Dynamic, Cinema, Presentation, sRGB, Blackboard, Theatre |
| Special Features | AV Mute Slide, CEC Support, Digital Zoom, Direct Power On/Off, Document Camera Compatible, OSD Copy Function, Quick Corner, Split Screen |
| Built-in Speaker | 5W |
