Technical specifications
| Main Input Voltage | 230 V AC 1 phase |
|---|---|
| Input Specifications | Input voltage: 220 V / 240 V |
| Input Specifications | Input Connection Type: IEC 320 C14 |
| Input Specifications | Input voltage limits: 151...302 V adjustable / 160...286 V |
| Input Specifications | Network frequency: 50/60 Hz +/- 3 Hz auto-sensing |
| Output Specifications | Output voltage: 230 V AC 1 phase / 220 V / 240 V |
| Power Rating | Rated power in W: 1000 W |
| Power Rating | Rated power in VA: 1500 VA |
| Output Specifications | Output connection type: 8 IEC 320 C13 / 2 IEC Jumpers |
| Performance & System | Harmonic distortion: Less than 5 % |
| Power Rating | Maximum configurable power in VA: 1500 VA |
| Power Rating | Maximum configurable power in W: 1000 W |
| Performance & System | Transfer time: 6 ms typical : 10 ms maximum |
| UPS Topology | UPS type: Line interactive |
| Performance & System | Wave type: Sine wave |
| Output Specifications | Output frequency: 50/60 Hz +/- 3 Hz sync to mains |
