Technical specifications
| Display | LCD 95 × 32 dots, 16 digits × 3 lines input. |
|---|---|
| Print Speed | Approx. 6 mm/sec. |
| Maximum Print Lines | 3 |
| Dimensions | ~52.5 × 167 × 223 mm. |
| Weight | ~610 g (without batteries). |
| Memory | Stores up to label text/layout/numbering/barcodes. |
| Keyboard | QWERTY layout |
| Usable Tape Widths | 6 mm, 9 mm, 12 mm, 18 mm, 24 mm |
| Print Method | Thermal‑transfer |
| Printing Resolution | 200 dpi |
| Max Print Height | 12 mm |
| Max Printing Lines | 3 lines (with 18/24 mm tape) |
| Fonts | 5 installed fonts (Sans‑serif, Sans‑serif italic, Sans‑serif rounded, Roman, Roman italic) |
| Character Styles | Normal, Bold, Outline, Shadow, Raised |
| Character Effects | Shading, Underline, Box |
| Numbering Function | Yes (1 to 999) |
| Barcode Printing | Yes |
| Frame Printing | Yes |
| Supported Languages | 14 languages (UI) + 6 message switch languages |
| Print Orientation | Horizontal / Vertical |
| Power Supply | Optional AC adaptor (AD‑A95100) or 6 × AA alkaline batteries (sold separately) |
| Dimensions (H × W × D) | Approx. 52.5 × 167 × 223 mm |
