Technical specifications
| Device Type | Indoor Wi‑Fi 7 Access Point |
|---|---|
| Wi‑Fi Standard | IEEE 802.11be (Wi‑Fi 7) |
| Frequency Bands | 2.4 GHz • 5 GHz • 6 GHz (Tri‑Band) |
| MIMO Configuration | 2×2 (2.4 GHz), 2×2 (5 GHz), 4×4 (6 GHz) |
| Max Aggregate Throughput | Up to 13.66 Gbps |
| Ethernet Ports | 1 × 5GE (PoE‑IN) • 1 × Gigabit Ethernet |
| USB Port | 1 × USB (for future expansion) |
| Bluetooth | BLE (Bluetooth Low Energy) |
| Recommended Clients | ~300 users |
| Max Supported Clients | Up to 1024 users |
| SSIDs | Up to 30 SSIDs |
| Transmit Power | 2.4 GHz: ~23 dBm5 GHz: ~23 dBm6 GHz: ~26 dBm (varies by region) |
| Smart Antennas | Built‑in Adaptive Smart Antenna Array |
| Security | WPA3, WPA2, 802.1X, Rogue AP Detection, ACL |
| Management | EasyWeb, Wireless Access Controller (WAC), eKit App, Cloud SNC |
| Mounting | Wall • Ceiling • Junction Box • T‑Rail |
| Dimensions (Ø×H) | 220 × 45 mm |
| Weight | ~0.745 kg (without packaging) |
| Operating Temp. | 0 °C – +50 °C |
| Operating Humidity | 5% – 95% non‑condensing |
