Technical specifications
| Scanner Type | Contactless / Overhead |
|---|---|
| Colour Modes | Colour / Greyscale / Monochrome |
| Resolution Horizontal Scanning | 285 to 218 dpi |
| Resolution Vertical Scanning | 283 to 152 dpi |
| Scanning Speed | 3 Seconds per page |
| Connections | USB 2.0 |
| Color | White |
| Warranty | 3 Years |
| Model | ScanSnap SV600 |
| Scanning Modes | Colour, Greyscale, Monochrome, Automatic detection |
| Image Sensor | Colour CCD x 1 with Lens reduction optics |
| Light Source | White LED + Lens illumination × 2 |
| Optical Resolution | Horizontal: 285 – 218 dpi Vertical: 283 – 152 dpi |
| Scanning Speed (A3 Landscape) | Normal 3 seconds / page (Colour/Greyscale 150 dpi, Mono 300 dpi) Better 3 seconds / page (Colour/Greyscale 200 dpi, Mono 400 dpi) Best 3 seconds / page (Colour/Greyscale 300 dpi, Mono 600 dpi) Excellent 3 seconds / page (Colour/Greyscale 600 dpi, Mono 1,200 dpi) |
| Document Size – Maximum | 432 × 300 mm (17.0 × 11.8 in.) |
| Document Size – Minimum | 25.4 × 25.4 mm (1 × 1 in.) |
| Document Thickness | 30 mm or less |
| Scan Start Methods | Normal scan, Timed interval scan, Page turning detection |
| Interface | USB 2.0 / USB 1.1 (Type-B) |
| Image Processing Functions | Deskew by text, Automatic paper size detection, Automatic rotation, Automatic colour detection, Book image correction (curvature), Multiple document detection |
| Power Requirements | AC 100 – 240 V, 50/60 Hz |
| Power Consumption | Operating 20 W or less, Sleep mode 2.6 W or less, Standby 0.4 W or less |
| Operating Temp & Humidity | Temperature: 5 – 35 °C Humidity: 20% – 80% (non-condensing) |
| Dimensions (W × D × H) | 210 × 156 × 383 mm |
| Weight | Approx. 3 kg |
| Environmental Compliance | ENERGY STAR® / RoHS / Ecodesign |
| Driver Support | ScanSnap specific driver (no TWAIN / ISIS support) |
